Sales: Jason Linley

Phone: 250-263-4555

 XL 5200 V base w/hydraulically expandable tracks·        10ft Telescoping boom w/180 degree rotation at base of boom

Engine

  • Model: Volvo TAD571 VE (Tier 4f)
  • 4-cylinder, liquid-cooled, electronically controlled
  • Gross Power: 173 hp @ 2200 rpm
  • Net Power: 153 hp @ 2200 rpm
  • Torque: 590 ft-lb

Fuel & Electrical

  • Fuel capacity: 99 gallons (375 L)
  • 24V system
  • Dual 1000 CCA batteries
  • 100 amp alternator

The 2012 Game Changer Foundation Rig is a purpose-built, high-performance machine designed for projects that demand precision, reach, and true multi-function capability. Its advanced boom and leader system enables full-directional inclination, making it ideal for complex foundation work across bridges, ports, rail, utilities, and difficult terrain. Built to adapt on the fly, the DDS7016E eliminates the need for multiple machines by handling diverse piling and drilling applications in one platform.

Follow us

DDS7016E 2012 Game Changer Foundation Rig

Price on request

Operational Modes:

  • Pile Driving
  • Screw Piling
  • Air Drilling
  • Auger Drilling
  • CFA (Continuous Flight Auger) Drilling
  • Vibratory Pile Driving

The boom and leader design allows operation:

  • Above ground
  • At ground level
  • Below ground

This gives contractors the flexibility to handle varying depths, slopes, and restricted-access sites without changing equipment.

Jason Linley

​P: 250 263 4555​

Sales: Jason Linley

Phone: 250-263-4555

Pricing: $2,493,420 CAD

Stability & Safety

  • Expandable tracks
  • Automatic braking systems
  • Real-time system monitoring
  • Built to SAE J1097 standards

DDS7016T  Truck Mounted "Game Changer" Foundation Rig

- 2003 Kenworth T800 Tridem w/2 sets of hydraulic outriggers
- 10ft Telescoping boom w/180 degree rotation at base of boom
- 14ft of upper cab hydraulic slide on truck bed - front to rear
- 46ft lead w/two grippens, crowd & service winch, foot & sliding carriage assy
- Rotary actuator at boom tip for lead assembly
- MHX12 Endeavor hydraulic hammer - 16,000 lb of force
- E70 Eskridge top drive - 70K ft/lbs capacity w/110 rpm max spin off
- 4" thru hole for grouting
- Full control/monitoring system for hammer & top drive

Drilling • Driving • Screw Piling

Download IFS Track Machine Specs for (1) ) DDS40C52X24E100. 2019.pdf

Truck-Mounted Option
Available in a truck-mounted configuration for:

  • Faster mobilization
  • Reduced transport costs
  • Efficient deployment in remote or highway-accessible sites

Maintains full drilling, driving, and screw piling capability of the crawler version.
Build & Design

  • Heavy-duty structural components
  • Self-erecting leader system
  • Ergonomic, all-weather operator cabin
  • Expandable tracks for stability
  • Low centre of gravity for safer operation
  • Compact transport dimensions

Copyright IFS Equipment, Innovative Foundation Solution Equipment. All rights reserved.

Multi-Function Capability

2012 349 cat hoe and 300 digga screw pile head

Monitoring & Control
Full in-cab monitoring system for:

  • Hammer performance
  • Top drive operation
  • Auger casting

Call Jason Linley for details

(250) 263-4555

President: Jason Linley (250) 263-4555

Machine Specifications

General

  • Year: 2012
  • Hours: 153.7
  • Serial #: PD30000001
  • Base: XL 5200 V (PD3000)
  • Model: DDS7016E

Boom & Leader

  • 12 ft telescoping boom with 180° rotation
  • 220° tilt, 105° pivot angle
  • Rotary actuator with 165° rotation

Mast options:

  • 40 ft base lead
  • 16 ft extension (total: 55 ft)

Gripping & Handling
Dual grippens:

  1. Top: material loading
  2. Bottom: alignment
  • 20,000 lb crowd & retract force
  • 8,000 lb service winch
  • Sliding carriage assembly

Counterweight

  • 15,500 lb (7,030 kg) counterweight
  • Hydraulically extendable

Hammer & Drive Options

  • Hammer: MHX24 Endeavor
  1. Up to 32,000 lb force
  • Top Drive: E100 Eskridge
  1. 35,000–100,000 ft-lb torque
  2. 100 rpm max spin
  3. 4" through-hole (grouting/air drilling)

Operator Cabin

  • Climate-controlled (A/C, heater, defroster)
  • Tinted safety glass
  • Adjustable seat with seatbelt
  • AM/FM radio
  • LED work and swing lights
  • Sliding front window and skylight

Controls

  • Dual electronic joysticks

  • Foot pedal crawler control
  • Self-centering safety controls
  • Dual-speed travel selection

Cat 349
7400hrs
75% of the hrs were for helical piles, 25% for digging.
Machine is also in great shape.
 Machine comes with 2 buckets
rhino hitches,
Digga UD 300 screw pile drive head
10 ft jib boom extensions, etc.
Machine is located in Edmonton, AB.

DDS40C52X24E100 Track Mounted "Game Changer" Foundation Rig

Download IFS Truck Mounted Machine Specs for (1) )DDS7016T.pdf

Equipment Sales

Travel & Mobility

  • High speed: 5.5 km/h
  • Low speed: 3.1 km/h
  • Gradeability: 58%
  • Drawbar pull: 170 kN

Hydraulic System

  • Load-sensing axial piston pump
  • Flow: up to 416 L/min
  • Pressures up to 4,900 psi
